R1820D60AAC-High-Rated USB Outlets-ELEGRP | Make Our Life Safer

R1820D60AAC

6.0 Amp USB Charger Dual Type A & Type C, 30W Duplex Tamper Resistant Outlet

6.0 Amp USB Charger Dual Type A & Type C, 30W Duplex Tamper Resistant Outlet

Add to list

- Tamper-Resistant (TR) Models: Complies with NEC requirements for 15A and 20A receptacles. Internal shutters block access unless a proper plug is inserted, enhancing household safety.
- Flame-Resistant Material: 5VA flame-retardant enclosure withstands high heat and resists ignition to help prevent fires.
- Ultra-Low Standby Power: Consumes less than 50 mW/h, saving more energy than ordinary USB outlets.
- Efficiency Level VI: Up to 87% energy efficiency (DOE & CEC tested), reducing energy costs when charging devices.
- Comprehensive Circuit Protection: Includes over-current, overload, over/under-voltage, short-circuit, and ESD protection to keep both the receptacle and devices safe.

Technical Parameters

Model

R1820D60AAC
Standard Color

White/Ivory/Light Almond/Black/Gray/Brown
Operating Temperature

-20℃ to 40℃
Product Size(HxWxD)

106x43x43mm
Certification

UL/CUL
Amperage

15A
Voltage

125V
Grade

Residential
Finish

Matte
Structure

Decorative
NEMA

5-20R
Pole & Wire

2-Pole, 3-Wire
Grounding

Grounding
Tamper Resistant

Yes
Weather Resistant

No
Wiring Method

Side Wire & Back Wire
Wiring Accom.

#12-#14AWG Copper Wire
Indicator light

NO
USB Type

Dual Type A & Type C
USB Rating

5V, 6.0A, 30W
Charging Protocol

DCP\BC1.2\Apple\Samsung
Indoor/Outdoor

Indoor Use Only
Overload Protection

Yes
Overheat Protection

Yes
Overvoltage Protection

Yes
Overcurrent Protection

Yes
Surge Protective

No
Enery Efficiency Level

Level VI
