2105L
Grounding Flush Mount Dryer Outlet, 30 Amp 125V/250V 14-30R Canada Standard
-
- Range and dryer devices offer heavy-duty connections in either surface mount or flush mount configurations.
- Heavy gauge galvanized steel mounting strap for corrosion resistance.
- Flush receptacles are completely ready-to-wire, shorten installation time significantly.
- Surface receptacles with adjustable cord clamp allow for wiring.
- Receptacles for use with copper or aluminum wire.
- Flush receptacles fit two-gang enclosure.
Technical Parameters
-
Model2105L
-
Standard ColorBlack
-
Product Size(HxWxD)137x137x57mm
-
CertificationUL/CUL
-
Amperage30A
-
Voltage125V/250V
-
GradeCommercial
-
StructureFlush Mount
-
NEMA14-30R
-
Pole & Wire3-Pole, 4-Wire
-
GroundingGrounding
-
Tamper ResistantNo
-
Weather ResistantNo
-
Wiring MethodBack Wire Only
-
Wiring Accom.AL/CU Wire
-
Indicator lightNO
-
Indoor/OutdoorIndoor
